AK Thermostat
Features
● Designed for electric heating equipment with a high-current switching capacity of up to 25 A.
● Precise and proven snap-action mechanism provides responsive and reliable temperature control.
● Silver contacts and heavy-duty terminals provide excellent durability and consistent switching performance.
Specifications
Electrical Rating
25 A, 250 VAC
Bulb Diameter
Ø4.5, Ø5.3, Ø8 mm
Capillary Length
24", 36", 48"
Stuffing Box
None / 1/4"-18 NPT / 3/8"-18 NPT
Temperature Range
60–200°C / 100–250°C / 80–300°C
150–400°F / 200–500°F / 200–550°F
150–400°F / 200–500°F / 200–550°F
Stem Flat Position at OFF
6:00
Ambient Temperature
-20–110°C (-4–230°F)
Dimensions
